CIRCUIT BREAKER 1P 1IN 30A QP

Non-interchangeable trip. 120 volt AC; 10,000 AIR. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (Full size only), General Switch, I-TE, Gould, Montgomery Ward and Sears. UL Listed, HACR rated. 15 and 20 amp UL Listed for frequent switching applications, 120 volt AC fluorescent lighting. 1" per pole.

• Actuator Type: Magnetic Thermal
• Current Rating: 30 A
• Dimensions: 1 in L x 3 in W x 3 in H
• Frame Size: 125 A
• Frame Type: QP
• Interrupt Rating: 10 kA
• Mounting Type: Plug-In
• Number of Phases: 1
• Number of Poles: 1
• Operating Frequency: 50/60 Hz
• Operating Temperature: 40 deg C
• Terminal Type: Lug
• Trip Type: Fixed
• Type: Miniature
• Voltage Rating: 120 V
• Wire Size: 14 to 6 AWG
