Siemens Q1515 Circuit Breaker, Duplex, Mini, 15 A, 1 -Pole, 120/240 V, Fixed Trip, Plug Mounting

Complete, unenclosed, molded case breaker with non-interchangeable trip. Takes the place of 2 single pole breakers in 1 in of space. Wire range: CU front #14 to # 8, AI from #12 to #6. Will replace American Switch, Westinghouse Type BR, Bryant, Challenger, Sylvania, Crouse-Hinds, Murray, Frank Adams, General Electric (full size only), General Switch, I-T-E, Gould, Montgomery Ward and Sears. HACR rated. 120/240 VAC, 10,000 AIR.
Unit: EA
UPC: 783643148246
Model Number: Q1515

• Actuator Type: Toggle
• Current Rating: 15 A
• Dimensions: 1 in L x 3 in W x 3 in H
• Frame Type: QT
• Interrupt Rating: 10 kA
• Mounting Type: Plug
• Number of Phases: 1
• Number of Poles: 1
• Operating Frequency: 50/60 Hz
• Operating Temperature: 40 deg C
• Suitable for: Siemens EQ Load Centers
• Terminal Type: Lug
• Trip Type: Fixed
• Type: Duplex Mini
• Voltage Rating: 120/240 V
• Wire Size: 12 to 8 14 to 8 AWG
